A front stage built as a system
8600iLR is the floorstanding left/right pair in the 8600i system. Separate bass, midrange, and tweeter sections share an internally braced cabinet, with the midrange and tweeter isolated in their own chamber.
The speakers are designed for use with a dedicated subwoofer. Rear acoustic controls help adjust them to the room, while the 8600iC provides the matching center channel. The manual covers placement, aiming, and the bi-wiring option.
In the room
| Woofer | (2) 8″ Glass Fiber |
|---|---|
| Midrange | (2) 5.25″ Glass Fiber |
| Tweeter | 1″ Soft Dome Low Resonance Tweeter™ |
| Passive Radiator | (2) 8″ Glass Fiber |
| Frequency Response (± 3dB) | 30Hz – 23kHz |
| Nominal Impedance | 6Ω |
| Crossover Type | Computer designed Butterworth 4th order asymmetrical time aligned Linkwitz-Riley |
| Sensitivity | 93dB |
| Recommended Amplifier Power | 50 – 300 Watts RMS |
| Dimensions w/ grilles(W x H x D) | 10.6 x 51.4 x 10in 269 x 1305 x 276mm |
| Weight (ea) | 88.2lbs, 40kg |
| Type | Sealed-box, 3-way |
| Frequency Response | 30Hz – 23kHz ±3dB |
