Surround channels within the wall
IW-155SR places the surround channels inside the wall instead of in cabinets beside the seating. A switch selects dipole or bipole operation to suit the intended surround arrangement.
The in-wall format is useful when visible speaker cabinets would interrupt a walkway or the room layout. Confirm the wall opening, mounting depth, and wiring route before installation.
| Type | 2-way dipole/bipole switchable |
|---|---|
| Woofer | (2) 5 ¼” (135mm) GLH* |
| Tweeter | (2) 1” (25.4mm) soft dome |
| Controls | Front panel Dipole/Bipole switch |
| Frequency Response | 80-20kHz ±3dB |
| Nominal Impedance | 6Ω |
| Crossover Frequency | 3500Hz |
| Sensitivity | 88dB |
| Recommended Amplifier | 25 – 150 Watts |
| Dimensions (W x H x D) | 115½ x 8½ x 3¾ (395 x 216 x 97mm) |
| Cutout Dimensions (W x H) | 14¼ x 71⁄8” (362 x 181mm) |
| Optimum Sealed Enclosure Volume | 1.0 cu ft. |
| Weight (ea) | 8lbs; 3.7kg |
| Optional Back Box | IN-BOX-155LCR |
